Endress + Hauser iTEMP TMT125 DIN rail temperature transmitter

Transformation of sensor signals into standardized digital output signals for all industries

Unsurpassed reliability, accuracy and long-term stability in critical processes over all industries.

The configurable transmitter not only transfers digital converted signals from RTD and TC sensors, it also transfers

resistance and voltage signals using FOUNDATION Fieldbus™ communication. High measurement point availability

by means of sensor monitoring functions and device hardware fault recognition.

Optionally, installation on DIN rail according to IEC 60715 or in a field housing.

Benefits

Universal temperature transmitter for up to 8 input signals

Sensor monitoring: cable open circuit, short-circuit and wiring error

Device hardware fault recognition for reliable operation and easy maintenance

Galvanic isolation between fieldbus and sensor inputs and between the input channels

Ex-Certification: FM IS, NI; ATEX Ex ia, Ex na for intrinsically safe installation in zone 1 and as associated apparatus in zone 2

Independent installation of connected temperature sensors in zone 0

Transducer block 'concentrator' and Multiple Analog Input Block (MAI) allow for effective and fast configuration of the relevant parameters

Field of application

Temperature transmitter with 8 input channels and FOUNDATION Fieldbus™ protocol for converting

various input signals into digital output signals

Input: Resistance thermometers (RTD), thermocouples (TC) resistance transmitters (Ω), voltage transmitters (mV)

DIN rail mounting as per IEC 60715 and with aluminum housing for field operation
