IN STOCK Schneider ABL6TS10G Voltage transformer Brand New with Good Discount

100% New & Original with very competitive price and One year Warranty

ABL6TS10G

Please contact us for more information.

Schneider ABL6TS10G Voltage transformer

Voltage transformer - 230..400 V - 1 x 115 V - 100 VA

Main

range of product : Phaseo Optimum

product or component type : Safety and isolation transformer

rated power in VA : 100 VA

input voltage

230 V AC single phase, terminal(s): N-L1

400 V AC phase to phase, terminal(s): L1-L2

output voltage : 115 V AC

secondary winding: Single

protective cover : Without

ambient air temperature for operation : -20…50 °C

Complementary

input voltage limits

360...440 V

207...253 V

network frequency limits : 47…63 Hz

input voltage tolerance : +/- 15 V

efficiency : 86 %

power dissipation in W : 16.3 W

output sustained overvoltage : 8 % (no load, hot state)

maximum voltage drop at rated load : 0.6 %

no load losses : 7.1 W

short-circuit voltage : 0,0751

operating altitude : 3000 m

electrical insulation class : Class B

width : 85 mm

height : 94 mm

depth : 86 mm

net weight : 2.1 kg

ABL6TS10G details1

ABL6TS10G details2
