Big sale for stock ! PEPPERL+FUCHS Inductive sensor NBB15-30GM50-E2 New & Original with very competitive price and One year Warranty

New & Original

NBB15-30GM50-E2

Please contact us for more information.

PEPPERL+FUCHS Inductive sensor NBB15-30GM50-E2

Basic series

15 mm flush

Increased operating distance

General specifications

Switching function: Normally open (NO)

Output type:PNP

Rated operating distance: 15 mm

Installation: flush

Output polarity DC

Assured operating distance:0 ... 12.15 mm

Reduction factor rAl: 0.3

Reduction factor rCu: 0.3

Reduction factor r304: 0.75

Output type: 3-wire

Nominal ratings

Operating voltage: 10 ... 30 V

Switching frequency: 0 ... 200 Hz

Hysteresis: typ. 5%

Reverse polarity protection: reverse polarity protected

Short-circuit protection: pulsing

Voltage drop: ≤ 3 V

Operating current: 0 ... 200 mA

Off-state current: 0 ... 0.5 mA typ. 0.1 µA at 25 °C

No-load supply current: ≤ 15 mA

Switching state indicator: all direction LED, yellow

Functional safety related parameters

MTTFd: 1058 a

Mission Time (TM):20 a

Diagnostic Coverage (DC):0 %

NBB15-30GM50-E2
