IN STOCK SCHNEIDER RM17TG20 Modular 3-phase supply control relay, 5 A, 2 CO, 208...440 V AC
Main
range of product : Zelio Control
product or component type : Modular measurement and control relays
relay type :Control relay
product specific application : For 3-phase supply
relay name : RM17TG
relay monitored parameters : Asymmetry
Phase sequence : time delay
Without
switching capacity in VA
1250 VA
measurement range
208...480 V voltage AC
Complementary
maximum switching voltage
250 V AC
250 V DC
minimum switching current
10 mA at 5 V DC
supply voltage limits
183…484 V AC
control circuit voltage limits
- 12 % + 10 % Un
power consumption in VA
0…22 VA at 400 V AC 50 Hz
voltage detection threshold
< 100 V AC
control circuit frequency
50...60 Hz +/- 10 %
output contacts
2 C/O
nominal output current
5 A
measurement voltage limits
183…528 V AC
delay at power up
650 ms
voltage range
183...484 V
response time
<= 130 ms (in the event of a fault)
marking
CE
overvoltage category
III conforming to IEC 60664-1
insulation resistance
> 500 MOhm at 500 V DC conforming to IEC 60255-5
> 500 MOhm at 500 V DC conforming to IEC 60664-1
[Ui] rated insulation voltage
400 V conforming to IEC 60664-1
supply frequency
50/60 Hz +/- 10 %
operating position
Any position without
connections - terminals
Screw terminals, 1 x 0.5...1 x 4 mm² (AWG 20...AWG 11) solid without cable end
width
17.5 mm
net weight
0.13 kg
