IN STOCK ABB AX561 ,1TNE968902R1301 AX561:S500,Analog IO.Mod.4AI/2AO U/I 12bit+sign, 24VDC, 2-wire in, 1-wire out
- Product description
- Contact us
ABB AX561 ,1TNE968902R1301 AX561:S500,Analog IO.Mod.4AI/2AO U/I 12bit+sign, 24VDC, 2-wire in, 1-wire out
AX561
General Information
Extended Product Type:AX561
Product ID:1TNE968902R1301
ABB Type Designation:AX561
EAN:6943747170190
Catalog Description:AX561:S500,Analog IO.Mod.4AI/2AO U/I
Long Description:AX561:S500,Analog IO.Mod.4AI/2AO U/I 12bit+sign, 24VDC, 2-wire in, 1-wire out
Additional Information
ABB Type Designation:AX561
Ambient Air Temperature:Operation 0 ... +60 °C
Storage -40 ... +70 °C
Analog Inputs:4 channels, 0 ... 20mA, 4 ... 20mA, 0 ... +5V, 0 ... +10V, -2.5 ... +2.5V, -5V … +5V, usable as digital input, 11bit + sign
Analog Outputs:2 channel, 0 ... 20mA, 4 ... 20mA, -10 ... +10V, 12bit + sign
Country of Origin:China (CN)
Customs Tariff Number:85371091
Degree of Protection:IP20
EAN:6943747170190
EPLAN Catalog Tree:Electrical engineering / PLC / General
Gross Weight:0.17 kg
I/O Option:eCo-IO module with Onboard IO - 4AI / 2AO
Invoice Description:AX561:S500,Analog IO.Mod.4AI/2AO U/I
Maximum Operating Altitude Permissible:2000 m
Maximum Order Quantity:150 piece
Minimum Order Quantity:1 piece
Mounting Position:Horizontal, Vertical possible with derating
Mounting Type:DIN rail and panel mounting
Mounting on DIN Rail:TH35-15 (35 x 15 mm Mounting Rail) acc. to IEC 60715
Number of Analog Configurable I/Os:4
Order Multiple:1 piece
Primary Voltage:24 V
Product Main Type:AX561
Product Name:Distributed Automation I/Os
Product Net Height:74 mm
Product Net Length:135 mm
Product Net Weight:0.13 kg
Product Net Width:34 mm
Product Type:PLC-AC500-eCo
Programming Software:AC500 Control Builder PS501-PROG
RoHS Status:Following EU Directive 2002/95/EC August 18, 2005 and amendment
Short Description:AX561:S500,Analog IO.Mod.4AI/2AO U/I
WEEE B2C / B2B:Business To Business
WEEE Category:5. Small Equipment (No External Dimension More Than 50 cm)
