ABB TBX5 pH, Redox (ORP) sensors with diagnostics ,TB564 and TBX564 high pressure hot-tap retractable sensors
Measurement made easy
The most durable pH / Redox (ORP) sensors in the world Next Step™ Solid State reference
• eliminates poisoning, pumping and plugging Advantage™ series with solution ground rod
• permits continuous sensor diagnostics Comprehensive selection of measuring electrodes
• sensors designed to suit all application requirements Combination style construction
• measuring, reference and temperature elements, all in one compact body Insertion, submersion, flow-through and hot-tap
• increases flexibility of installation Operating temperatures up to 140 °C (284 °F)
• the highest glass temperature limit on the market Operating pressures up to 21 bar (300 psi) and higher
• the highest pressure limit on the market
Body style
Sensor bodies are constructed of Kynar (PVDF) or Ryton (PPS). TB5 series sensors use Solid-State Next Step
references. The TBX5 series denotes Next Step Advantage types with integral solution ground.
TB564 and TBX564 high pressure
hot-tap retractable sensors TB(X)564 are high pressure, hot-tap, ball valve, insertion
sensors. They permit sensor maintenance or replacement without interrupting the process.
For safety reasons, it is recommended that the operating pressure be reduced below 690 kPa (100 psi) during insertion
and retraction of the sensor assembly.
Specification
Applications
High pressure, hazardous materials
Maximum pressure / temperature
2065 kPa (300 psi) at 140 °C (284 °F)
Features
Insert / retract without complete process shutdown*
Retraction housing for safety
Taps for flushing or pressurizing
Material
Electrode body Kynar (PVDF)
Ball-valve / hardware 316 stainless steel
External O-rings Viton
Junction Wood or PTFE
Junction types Flush
Notched
ABB TBX5 Series
TB551 and TBX551 Ryton sensors
TB556 and TBX556 Kynar sensors
TB557 and TBX557 hot-tap retractable sensors
TB561 and TBX561 Sterilizable sensors
TB564 and TBX564 high pressure hot-tap retractable sensors
TB567 and TBX567 high pressure in-line sensors
