YOKOGAWA Contacting Conductivity Sensors FS40-S22WE 2/4-electrode design for Conductivity Flow fittings, Subassemblies and Immersion fittings

100% New & Original with very competitive price and One year Warranty
FS40-S22WE
YOKOGAWA Contacting Conductivity Sensors FS40-S22WE 2/4-electrode design for Conductivity Flow fittings, Subassemblies and Immersion fittings
Need a Quote?
Please contact us for more information.

YOKOGAWA Contacting Conductivity Sensors FS40-S22WE 2/4-electrode design for Conductivity Flow fittings,

Subassemblies and Immersion fittings



Model SC42 and FF40/FS40/FD40 2/4-electrode design for Conductivity Flow fittings, Subassemblies and Immersion fittings


The sensor, model SC42 and associated fitting program is designed to meet the most common installation requirements in terms of material compatibility,

process connections and flow dynamics. Model SC42 sensor, available in various materials such as Epoxy, Stainless Steel,

PTFE and PVDF, is intended to suit most process conditions.


The sensor is provided either with a Amphenol connector to fit the Yokogawa WU40 cable or Variopin connector to fit with Yokogawa

WU10/WE10-cable. A wide range of flow and immersion fittings makes it possible to install the sensor in a permanent or semi-permanent location.

The fittings of stainless steel might be used in sanitary applications


Features

• Built-in temperature resistor: Pt1000

• Fast temperature response

• Plug and cable form a water tight connection to IP67

• Selection of cell constant 0.01 cm-1 to 10 cm-1

• Sensor with 8 pin Variopin with ID chip for SENCOM SA11-C1 use

• ATEX/IECEx certified

• Wide range of sensors to suit most process conditions including ultra-pure water applications

• Wide range of mountings

• Standard quality inspection certificate with delivery of sensor


Model SC42 Measuring elements

2-electrode for SC42-SP/SV series; SC42-EP04 (EP14); SC42-EP15 (EP16) series

4-electrode for SC42-EP08 (EP18); SC42-FP/FV08 (TP/TV08) Pt1000 temperature sensor





SC42 details
