PEPPERL+FUCHS Inductive sensor NJ8-18GM-N
Features
* 8 mm non-flush
* Usable up to SIL 2 acc. to IEC 61508
Technical Data
General specifications
Switching function Normally closed (NC)
Output type NAMUR
Rated operating distance sn 8 mm
Installation non-flush
Assured operating distance sa 0 ... 6.48 mm
Reduction factor rAl 0.4
Reduction factor rCu 0.3
Reduction factor r304 0.85
Output type 2-wire
Nominal ratings
Nominal voltage Uo 8.2 V (Ri
approx. 1 kΩ)
Operating voltage UB 5 ... 25 V
Switching frequency f 0 ... 200 Hz
Hysteresis H 3 %
Current consumption
Measuring plate not detected ≥ 3 mA at nominal voltage
Measuring plate detected ≤ 1 mA at nominal voltage
Ambient conditions
Ambient temperature -25 ... 100 °C (-13 ... 212 °F)
Mechanical specifications
Connection type cable PVC , 2 m
Core cross-section 0.75 mm2
Housing material Stainless steel 1.4305 / AISI 303
Sensing face PBT
Degree of protection IP67
Cable
Cable diameter 6 mm ± 0.2 mm
Bending radius > 10 x cable diameter
