PEPPERL+FUCHS Power Feed Module KFD2-EB2
Features
• Interface for Power Rail
• Supply current ≤ 4 A
• Replaceable fuse
• Relay contact output, reversible
• LED status indication
Function
The power feed module supplies the Power Rail with a voltage of 24 V DC and a maximum current of 4 A.
In the event of a device fault or a wiring fault of any isolator on the Power Rail, the collective error messaging relay alerts the controller via a binary I/O point.
This relay can be configured as normally-open or normally-closed. A green LED on the front of the device indicates the power state, and a red LED lights up during a fault condition.
In the sense of functional safety (SIL) the device provides no dangerous failures.
Thereby the safe condition of the supplied isolators must be defined as the de-energized state.
Thus the device will not influence the safety calculation or the SIL value. This device is compatible with all versions of the Power Rail.
