In stock PEPPERL+FUCHS Universal Temperature Converter KFD2-UT2-Ex1 Intrinsic Safety Barriers Isolated Barriers K-System New & Original with very competitive price and One year Warranty
- Product description
- Contact us
PEPPERL+FUCHS Universal Temperature Converter KFD2-UT2-Ex1 Intrinsic Safety Barriers Isolated Barriers K-System
Features:
• 1-channel isolated barrier
• 24 V DC supply (Power Rail)
• Thermocouple, RTD, potentiometer or voltage input
• Current output 0/4 mA ... 20 mA
• Sink or source mode
• Configurable by PACTware
• Line fault (LFD) and sensor burnout detection
• Up to SIL 2 acc. to IEC 61508/IEC 61511
Function:
This isolated barrier is used for intrinsic safety applications. It is designed to connect RTDs, thermocouples, or
potentiometers in the hazardous area, and provide a proportional 0/4 mA ... 20 mA signal to the safe area.
The barrier offers 3-port isolation between input, output, and power supply.
A removable terminal block K-CJC-** is available for thermocouples when internal cold junction compensation is
desired. A fault is indicated by a red flashing LED per NAMUR NE44 and user-configured fault outputs.
The unit is easily programmed with the PACTware™ configuration software. A collective error messaging feature is
available when used with the Power Rail system.
