In Stock PEPPERL+FUCHS Transmitter Power Supply KFD2-CRG2-1.D New & Original with very competitive price and One year Warranty

New & Original

KFD2-CRG2-1.D

Need a Quote?

Please contact us for more information.

Product description
Contact us

In Stock PEPPERL+FUCHS Transmitter Power Supply KFD2-CRG2-1.D

New & Original with very competitive price and One year Warranty

1-channel signal conditioner

24 V DC supply (Power Rail)

Input 2-wire and 3-wire transmitters and 2-wire current sources

Output 0/4 mA ... 20 mA

2 relay contact outputs

Adjustable energized/de-energized delay

Programmable high/low alarm

Linearization function (max 20 points)

Line fault detection (LFD)

Up to SIL 2 acc. to IEC 61508/IEC 61511

Datasheet excerpt: Technical data of KFD2-CRG2-1.D

General specifications
Signal type		Analog input
Functional safety related parameters
Safety Integrity Level (SIL)		SIL 2
Supply
Connection		Power Rail or terminals 23+, 24-
Rated voltage		20 ... 30 V DC
Rated current		approx. 130 mA
Power dissipation		2 W
Power consumption		2.5 W
Interface
Programming interface		programming socket
Input
Connection side		field side
Connection		terminals 1, 2, 3
Input I
	Input signal	0/4 ... 20 mA
	Available voltage	≥ 15 V at 20 mA
	Open circuit voltage/short-circuit current	24 V / 33 mA
	Input resistance	45 Ω (terminals 2, 3)
	Line fault detection	breakage I < 0.2 mA; short-circuit I > 22 mA
Output
Connection side		control side
Connection		output I: terminals 10, 11, 12 output II: terminals 16, 17, 18 Output: analog terminals 8+, 7-
Output signal		0 ... 20 mA or 4 ... 20 mA
Output I, II		signal, relay
	Contact loading	250 V AC / 2 A / cos φ ≥ 0.7 ; 40 V DC / 2 A
	Mechanical life	5 x 10⁷ switching cycles
Output III		Signal, analog
	Current range	0 ... 20 mA or 4 ... 20 mA
	Open loop voltage	max. 24 V DC
	Load	max. 650 Ω
	Fault signal	downscale I ≤ 3.6 mA, upscale I ≥ 21.5 mA (acc. NAMUR NE43)
Energized/De-energized delay		0 ... 250 s , adjustable
Transfer characteristics
Input I
	Accuracy	< 30 µA
	Influence of ambient temperature	0.003 %/K (30 ppm)
Output I, II
	Response delay	≤ 200 ms at bounce from 0 ... 20 mA
Output III
	Resolution	≤ 10 µA
	Accuracy	< 20 µA
	Influence of ambient temperature	0.005 %/K (50 ppm)
	Reaction time	< 650 ms at bounce from 0 ... 20 mA at the input, 90 % of output full-scale value
Galvanic isolation
Input/Other circuits		reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 V_eff
Output I, II/other circuits		reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 V_eff
Mutual output I, II, III		reinforced insulation according to IEC/EN 61010-1, rated insulation voltage 300 V_eff
Output III/power supply and collective error		functional insulation acc. to IEC 62103, rated insulation voltage 50 V_eff
Interface/power supply and collective error		functional insulation acc. to IEC 62103, rated insulation voltage 50 V_eff
Indicators/settings
Display elements		LEDs , display
Control elements		Control panel
Configuration		via operating buttons via PACTware
Labeling		space for labeling at the front
Directive conformity
Electromagnetic compatibility
	Directive 2014/30/EU	EN 61326-1:2013 (industrial locations)
Low voltage
	Directive 2014/35/EU	EN 61010-1:2010
Conformity
Electromagnetic compatibility		NE 21:2006
Degree of protection		IEC 60529:2001
Ambient conditions
Ambient temperature		-20 ... 60 °C (-4 ... 140 °F)
Mechanical specifications
Degree of protection		IP20
Connection		screw terminals
Mass		300 g
Dimensions		40 x 119 x 115 mm (1.6 x 4.7 x 4.5 inch) , housing type C3
Mounting		on 35 mm DIN mounting rail acc. to EN 60715:2001
International approvals
UL approval		E223772
General information
Supplementary information		Observe the certificates, declarations of conformity, instruction manuals, and manuals where applicable. For information see www.pepperl-fuchs.com.
Accessories
Optional accessories		- power feed module KFD2-EB2(.R4A.B)(.SP) - universal power rail UPR-03(-M)(-S) - profile rail K-DUCT-GY(-UPR-03) - FDT framework PACTware 4.1 - device type manager DTM Interface Technology - adapter K-ADP-USB
