In Stock Fluke 805 805CN Vibration Meter 100% New & Original with very competitive price and One year Warranty
- Product description
- Contact us
Fluke 805 Vibration Meter 100% New & Original with very competitive price and One year Warranty
Key features
* Reliable, repeatable, accurate device for checking bearings and overall vibration
* Features innovative sensor design that minimizes measurement variations caused by device angle or contact pressure
* Provides consistent data quality at both low and high frequency ranges
* Offers four-level severity scale to assess urgency of problems and bearing condition
Product overview: Fluke 805 Vibration Meter
The Reliable, Repeatable, Accurate Way to Check Bearings and Overall Vibration
Make go or no-go maintenance decisions with confidence.
The Fluke 805 Vibration Meter is the most reliable vibration screening device available for frontline mechanical troubleshooting
teams that need repeatable, severity-scaled readings of overall vibration and bearing condition.
What Makes the 805 the Best Choice?
* A meter – not a pen – that measures overall vibration as well as specific variables like bearing condition and temperature, to provide a more complete picture
* A combination vibration and force sensor tip that compensates for user variance (force or angle) yielding accurate, repeatable readings
* A four-level severity scale and onboard processor calculate bearing condition and overall vibration using easy-to-understand textual alerts (Good, Satisfactory, Unsatisfactory, Unacceptable)
* Sensor sensitivity can read a wide range of frequencies (10 to 1,000 Hz and 4,000 to 20,000 Hz) covering most machine and component types
* Straight-forward user interface that minimizes the user inputs to RPM range and equipment type
Other useful features:
* Measures overall vibration (10 Hz to 1,000 Hz) for acceleration, velocity, and displacement units of measurement for a wide variety of machines
* Provides Crest Factor+ technology for reliable bearing assessment using direct sensor tip measurements between 4,000 Hz and 20,000 Hz
* Compares vibration levels with ISO-10816 severity scales
* Allows you to view trending in Microsoft® Excel using pre-built templates
* Features colored lighting system (green, red) and on-screen comments to indicate how much pressure needs to be applied to take measurements
* Measures temperature with Spot IR Sensor to increase diagnostic capabilities
* Holds and saves up to 3,500 measurements in on-board memory
* Provides external accelerometer support for hard to reach locations
* Allows you to export data via USB
* Provides audio output for listening to bearing tones directly
* Features built-in flashlight for viewing measurement locations in dark areas
* Provides large high-resolution display for easy navigation and viewing
Specifications: Fluke 805 Vibration Meter
| Vibration Meter | ||
| Low frequency range (overall measurement) | 10 Hz to 1,000 Hz | |
| High frequency range (CF+ measurement) | 4,000 Hz to 20,000 Hz | |
| Severity levels | Good, satisfactory, unsatisfactory, unacceptable | |
| Vibration limit | 50 g peak (100 g peak-peak) | |
| A/D converter | 16-bit | |
| Signal to noise ratio | 80 dB | |
| Sampling rate | Low frequency | 20,000 Hz |
| High frequency | 80,000 Hz | |
| Real time clock backup | Coin battery | |
| Sensor | ||
| Sensitivity | 100 mV g ±10% | |
| Measurement range | 0.01 g to 50 g | |
| Low frequency range (overall measurement) | 10 Hz to 1,000 Hz | |
| High frequency range | 4,000 Hz to 20,000 Hz | |
| Resolution | 0.01 g | |
| Accuracy | At 100 Hz ±5% of measured value | |
| Amplitude Units | ||
| Acceleration | g, m/sec² | |
| Velocity | in/sec, mm/sec | |
| Displacement | mils, mm | |
| Infrared Thermometer (Temperature Measurement) | ||
| Range | -20°C to 200°C (-4°F to 392°F) | |
| Accuracy | ±2°C (4°F) | |
| Focal length | Fixed, at ~3.8 cm (1.5 in) | |
| External sensor | ||
| Fluke supports but does not provide external sensors | ||
| Frequency range | 10 Hz to 1,000 Hz | |
| Bias voltage (to supply power) | 20 VDC to 22 VDC | |
| Bias current (to supply power) | Maximum 5 mA | |
| Firmware | ||
| External interfaces | USB 2.0 (full speed) communication | |
| Data capacity | Database on internal flash memory | |
| Upgrade | Through USB | |
| Memory | Up to 3,500 measurements | |
| Radiated Emission | ||
| Electrostatic discharge: burst | Standard EN 61000-4-2 | |
| Electromagnetic interference | Standard EN 61000-4-3 | |
| RE | Standard CISPR 11, Class A | |
| Environmental | ||
| Operating temperature | -20°C to 50°C (-4°F to 122°F) | |
| Storage temperature | -30°C to 80°C (-22°F to 176°F) | |
| Operating humidity | 10% to 95% RH (non-condensing) | |
| Operating/storage altitude | Sea level to 3,048 meters (10,000 feet) | |
| IP rating | IP54 | |
| Vibration limit | 500 g peak | |
| Drop test | 1 meter | |
| General Specifications | ||
| Battery type | AA (2) Lithium Iron Disulfide | |
| Battery life | 250 measurements | |
| Size (L x W x H) | 24.1 x 7.1 x 5.8 cm (9.5 x 2.8 x 2.3 in) | |
| Weight | 0.40 kg (0.89 lb) | |
| Connectors | USB mini-B 7-pin, stereo audio output jack (3.5 mm Audio Plug), external sensor jack (SMB connector) | |
There have More other details options , pls kindly contact with Chris directly to know more details information .
Chris Fang
Sales Engineer
Sunup (Wuhan) Import and Export Co., Ltd.
Add:7-A16,Caishen Commercial Plaza,Hankou Railway Station,Wuhan, China
Postal code:430015
M: + 86-15926376631(WhatsApp & Wechat)
Skype: live:chris_61491
Email: chris@sunupauto.com
